PRODUCTION
產品項目 |
MM |
INCH/AWG |
|
Single wire size
單線徑 |
0.05-2.5 |
44 -11 |
|
Bifilar wire size
雙線徑 |
2×1.8 |
2×131/2 |
|
Finished core O.D.
完成外徑 |
5.0-320 |
0.2 – 13 |
|
Finished core I.D.
完成內徑 |
From 1.5 |
From 0.06 |
|
Finished core height
完成鐵心高度 |
Upto 150 |
Upto 5.9 |
|
Tape size
包帶尺寸 |
4 -30 |
0.05-1.18 |
|
TECHNICAL DATA/技術數據:
|
COMBINATIONS/機器結合 |
|
21 Interchangeable heads/可互換機頭 |
|
4 Slider heads /邊滑器式機頭 VU10, VU20,VU30, VU40 |
|
5 Gear rack heads/齒條式機頭VU0,VU1, VU2, VU3,VU4 |
|
5Belt heads/皮帶式機頭 VU60,VU100, VU200,VU200-V,VU300 |
|
7Taping head/包帶機頭 VU0/B,VU1/B, VU2/B,VU3/B VU4/B VU200/B,VU300/B |
|
6 Roller tables/滾子臺架 VU111,VU111-V, VU112,VU222, VU222-V,VU332 |
| |
MACHINE FEATURES 機器特點
l CONTROLLER控制器
PLC CONTROL WITH SOFTWARE LANGUAGES: EN.CH./ PLC可編程控制器,中英文兩種操作語言
l DISPLAY顯示
LCD-DISPLAY WITH BACKGROUND ILLUMINATION: CONTINUOUS READ OUT OF OPERATION DETAILS
/液晶顯示速度及操作信息
l PRESETS設定
60 PROGRAMS, / 60種程序
EACH PROGRAM CONTAINS OF 8 SEQUENCES /每個程序包含8段
l PROGRAMMING程序
USER FRIENDLY TEXT COMMANDS/采用簡單文本命令設定
l DATA MEMORY AND OUTPUT
數據存儲與輸出
INTERFACES FOR PC
INTERFACE FOR SOFTWARE UPDATES/PC數據線輸入/軟件可以升級
l WINDING SPEED繞線速度
UP TO 1800 RPM 最高可達1800RPM
SEPARATELY PROGRAMMABLE LOAD SPEED
SEPARATELY PROGRAMMABLE WIND SPEED/可設定儲線速度和繞線速度
l CORE DRIVE鐵芯驅動
STEPPER MOTOR 0,30 KW/步進馬達0.30KW
l WIRE PITCH CONTROL線距控制
FULLY AUTOMATIC PITCH CHANGE,
PROGRAMMABLE IN STEPS OF 0,001mm/線距可自動調節
l CORE INDEX & REVERSE CONTROL
鐵芯正反轉
FULLY AUTOMATIC/全自動
l ACCELERATION & DECELLERATION
增速、減速
FULLY AUTOMATIC/全自動
l STOPS FOR TAPS抽頭停機
AUTOMATIC/全自動
l SECTOR & BANK WINDING CONTROL
FULLY AUTOMATIC/全自動
l WINDING HEAD DRIVE繞線機頭驅動
SERVO MOTOR 0,8 KW /伺服馬達0,8 KW
l TAPING OPERATION 包帶操作
FULLY AUTOMATIC /全自動
l SUPPLY VOLTAGES提供電源
230 (110 AND 240) VOLT, 50 HZ AC
l MACHINE SIZE AND WEIGHT
機器尺寸及重量
800×700 MM 110 KG NET, 130 KG GROSS |
